Facial Recognition Facial Detection And Analytics Face picture comparison, human face capture, face picture search Face Picture Library Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB) Facial Detection And Analytics Performance 1-ch human face capture Face Picture Comparison 4-ch face picture comparison alarm Motion Detection 2.0 Human/Vehicle Analysis 8-ch Video And Audio IP Video Input 8-ch Incoming Bandwidth 80 Mbps Outgoing Bandwidth 160 Mbps HDMI Output 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz VGA Output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz Video Output Mode HDMI/VGA independent output CVBS Output N/A Audio Output 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) Two-Way Audio 1-ch, RCA (Linear, 1 KΩ) Decoding Decoding Format H.265/H.265+/H.264+/H.264 Recording Resolution 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Synchronous Playback 8-ch Decoding Capability AI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps) AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30 fps) Stream Type Video, Video & Audio Audio Compression G.711ulaw/G.711alaw/G.722/G.726/AAC Network Remote Connection 128 Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS Network Interface 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface PoE Interface 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface Power ≤ 80 W Standard IEEE 802.3af/at Auxiliary Interface SATA 2 SATA interfaces Capacity Up to 10 TB capacity for each HDD USB Interface Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 Alarm In/Out 4/1 General Power Supply 48 VDC, 2.5 A Consumption ≤ 15 W (without HDD, and PoE off) Working Temperature -10 °C to 55 °C (14 °F to 131 °F) Working Humidity 10% to 90% Dimension (W × D × H) 385 mm × 315 mm × 52 mm (15.2"× 12.4" × 2.0") Weight ≤ 3 kg (without HDD, 6.6 lb.)
